SPECIFICATION

• Camera : WDR Binocular Camera @ 1MP

• Operation System : Linux

• CPU: Dual Core@1GHz

• RAM: 512MB; ROM: 8GB

• Speaker : 8ohm @1W

• Microphone : *1 (Sensitivity: -42 dB/ Omni-directional/ Signal-to-Noise Ratio: 58 dB/ Impedance: 2.2kΩ)

• Supplement Light: No

• Fingerprint Sensor: In-Glass Fingerprint (Z-ID) (SenseFace 3A)

• Authentication Method : SenseFace 3A: Fingerprint / Face / Card / Password (Virtual Keypad)

                                         SenseFace 3B: Face / Card / Password (Virtual Keypad)

• Fingerprint Template Capacity : SenseFace 3A: 6,000 (1:N) (Standard)

                                                     SenseFace 3B: /

• Face Template Capacity : 3,000 (1:N) (Standard)

• Card Capacity : 6,000 (1:N) (Standard)

• User Capacity : 6,000 (1:N) (Standard)

• Transaction Capacity : 150,000 (1:N)

• Max. User Password Length : 8 Digits

• Optional Functions : IC Card, Wi-Fi, Wireless Doorbell

• Power Supply : DC 12V 3A

• Operating Temperature : -5°C to 45°C

• Operating Humidity : 10% to 90% RH (Non-condensing)

• Dimensions : 166 mm * 63 mm * 25 mm (L*W*H)

• Net Weight : 0.185 Kg

• Supported Software : On-Premise Software: ZKBio CVAccess (AC PUSH) & ZKBio Time (TA PUSH)

                                     Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App)

• Installation : Wall-mount (Compatible with Asian Gang Box / Single Gang Box)

• Ingress Protection Rating : IP65 (waterproof and dustproof )

• Certifications : ISO14001, ISO9001,CE, FCC, RoHS
