SPECIFICATION

• Material : Optical

• CPU : 120MHz DSP

• Flash : 16 KB

• SoC : RTOS

• Image Quality : 0.3 million pixels CMOS

• Sunlight Operation : White filed, General Sunlight

• Water Splash : YES

• Card Reader : 125KHz EM & 13.56MHz Mifare

• Operating System : Windows2000/XP/2003/Vista/7/8(32/64bit)

• LED : Green

• Power Voltage : 5V (USB)

• Power Current : 300mA

• Communication : USB 2.0 / USB1.1 / USB1.0

• Interface Socket : USB Type A

• Image Resolution : 500 dpi

• Effective Collecting Area : 13.24 * 15.7 mm

• Collecting Area : 15.4*18 mm

• Image Size : 280*360 pixel

• Dimension : 124.5 * 102 * 34mm (L*W*H)

• Gray Level : 256

• Weight : 0.27kg

• Operating Environment : -20 °C ~ +50 °C; 90% r.h.
