Specification

.  Port: 8x 10/100/1000Mbps PoE port (RJ45), 1 x 10/100/1000Mbps port (RJ45), 1 x Gigabit SFP

.  Standard: IEEE 802.3af, IEEE 802.3 at

.  Switching capacity: 20Gbps

.  Forwarding performance: 14.88Mpps

.  MAC: 8K

.  Max. PoE Power: Max capacity: 120W Max capacity for single port: 30W

.  EXTEND(Surveillance mode): Transmission distance up to 250 meters

.  Allows up to 10 VLANs with IDs from 1 to 4094

.  Support: Loop Detection, port isolation

.  Dimensions (W×D×H): 169*132*40mm

.  Supports visiting the cloud by scanning the QR code to mobile App (UNV Link Pro Tool)

.  Ambient temperature: 0°C to 45°C (32°F to 113°F)

.  Weight: <0.85kg

.  Power supply: AC: 100V to 240V, 50/60Hz, 125W
