SPECIFICATION
• Network Port : 4 10/100Mbps PoE RJ45 port (Port 1~ port4)
• Network Port :2 10/100Mbps RJ45 port uplink (Port5~port 6)
• Transfer Rate: 100Mbps full Duplex, 10 or 100Mbps Half Duplex
• Network protocol: IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
• Bandwidth: 1.2Gbps (no block)
• Network delay (100 to 100M bps): maximum 20 μs (using 64 byte packet)
• Frame filtering and transmission rate: 10M port maximum 14,800pps,
• 100M port maximum 148,800pps
• LED indicator:
• LINK/ACT
• RESV
• PoE Indicator light
• PoE pin: 1/2+, 3/6-
• Max power for single port 30W
• Internal power adapter: 60W
• Power adapter input: 52V 1.15A
• Dimensions: Size (L x W x H): 125mm x 75mm x 27mm
• Weight: 0.5kg
• Operating Temperature: 0°~40°C
• Operating Humidity: 10%~ 90%, non-Condensing
• safety: CE/ROHS/FCC/CCC
