Specifications

• Dimensions : 308.5 * 308.5 * 67.5

• Weight : 1.8kg

• Power : 1.2 - 4.2W

• Frequency  E: 865MHz - 868MHz

  F: 902MHz - 906MHz (adjustable)

• Communication Interface : Wiegand, RS485, USB configuration parameters

  (Wiegand, RS485 requires one of two options)

• Interface Protocol : EPC global UHF Class 1 Gen 2 / ISO 18000-6C

• Working Mode : Read Always (Default) and Read by Trigger

• Output Power : 19dBm - 30dBm

• Protection Level : IP66

• Working Voltage : DC 9 - 15V

• Storage Temperature and Humidity : -20°C - 80°C, < 85%

• RS485 Communication : Optional baud rate (9600, 19200, 38400, 57600, 115200), the default is 115200
